✓ Smart Features

Alarm Trigger Motion detection, network disconnected, IP address conflict, illegal login, HDD full, HDD error

✓ Camera

Image Sensor 1/2.7″ Progressive Scan CMOS
Min. Illumination Color: 0.028 Lux @ (F2.0, AGC ON)
Shutter Speed 1/3 s to 1/100,000 s
Slow Shutter Yes
Angle Adjustment Pan: 0° to 360°, tilt: -90° to 90°, rotate: 0° to 90°
WDR DWDR
Day & Night IR Cut Filter

✓ Lens

Aperture F2.0
Focus Fixed
FOV

2.8 mm, horizontal FOV: 114.5°, vertical FOV: 62°, diagonal FOV: 135.5°

4 mm, horizontal FOV: 86°, vertical FOV: 46.5°, diagonal FOV: 102.5°

Lens Mount M12
Focal Length 2.8/4 mm

✓ Network

Network Storage Support micro SD/SDHC/SDXC card (max. 256 GB), local storage and NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
Alarm Trigger Motion detection, illegal login
Protocols TCP/IP, ICMP, DHCP, DNS, DDNS, HTTP, RTP, RTSP, NTP, UPnP, IGMP, IPv6, UDP, QoS, Bonjour
API ISAPI
Simultaneous Live View Up to 6 channels
User/Host

Up to 32 users

3 levels: Administrator, Operator and User

Client

Wired network: Hik-Connect, iVMS-4200

Wi-Fi: iVMS-4200

*Wi-Fi connection with Hik-Connect directly is not possible.

Web Browser

Plug-in required live view: IE8, IE9, IE10, IE11

Local service: Chrome 57.0+, Firefox 52.0+

General Function Anti-flicker, heartbeat, mirror, password protection, password reset via e-mail
Firmware VersionV5.5.101

✓ Video

Max. Resolution 1920 × 1080

✓ Audio

Environment Noise Filtering Yes
Audio Sampling Rate 8 kHz/16 kHz

✓ Interface

Reset Button Yes
On-Board Storage Built-in Micro SD/SDHC/SDXC slot, up to 128 GB
Communication Interface 1 RJ45 10M/100M self-adaptive Ethernet port
Audio 1 Built-in mic, mono sound

✓ Image

Max. Resolution 1920 × 1080
Main Stream

50Hz: 25 fps (1920 × 1080, 1280 × 720)

60Hz: 30 fps (1920 × 1080, 1280 × 720)

Sub-Stream

50Hz: 25 fps (640 × 360)

60Hz: 30 fps (640 × 360)

Image Enhancement BLC, HLC, 3D DNR
Day/Night Switch Day, night, auto, scheduled
Image Settings Saturation, brightness, contrast, sharpness, AGC, white balance adjustable by client software or web browser

✓ General

Operating Conditions -30 °C to +60 °C (-22°F to +140 °F), humidity 95% or less (non-condensing)
Power Supply 12 VDC ± 25%, Ø5.5 mm coaxial power plug
Power Consumption And Current 12 VDC, 0.4 A, max. 5 W
Material Front cover: metal, back cover: plastic
Dimensions

Camera: 177.6 mm × 67.8 mm × 66.2 mm (7″ × 2.7\” × 2.6\”)

With package: 264 mm × 129 mm × 120 mm (10.4 × 5.1\” × 4.7\”)”

Weight

Camera: approx. 270 g (0.6 lb.)

With package: approx. 470 g (1 lb.)

✓ Approval

ProtectionIngress protection: IP66 (IEC 60529-2013)
Compression Standard

Video Compression

Main stream: H.265+/H.265/H.264+/H.264
Sub-stream: H.265/H.264
H.264+Main stream supports
H.265+Main stream supports
H.264 TypeBaseline Profile/Main Profile
H.265 TypeBaseline Profile
Video Bit Rate 32 Kbps to 8 Mbps
Audio Compression G.711/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32 to 160Kbps(MP2L2)

✓ IR

IR Range Up to 30 m
Wavelength 850 nm

✓ Wi-Fi (-W)

Wireless Standards IEEE 802.11b/g/n
Frequency Range 2.4 GHz to 2.4835 GHz
Transfer Rates

11b: 11 Mbps

11g: 54 Mbps

11n: up to 150 Mbps

Security 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
Channel Bandwidth 20 MHz/40 MHz
Wireless Range Up to 80 m (The performance varies based on actual environment.)
Protocols

802.11b: CCK, DQPSK, DBPSK

802.11g/n: 64-QAM, 16-QAM, QPSK, BPSK
