Camera

• Image Sensor: 1/2.8″ Progressive Scan CMOS
• Max. Resolution: 1920 × 1080
• Min. Illumination: 0.01 Lux @ (F1.2, AGC ON), 0 Lux with IR
• Shutter Time: 1/3 s to 1/100,000 s
• Day & Night: IR cut filter with auto switch
• Angle Adjustment: Pan: 0° to 355°; Tilt: -10° to 90°

Lens

• Lens Type: Fixed Lens
• Focal Length & FOV: 2.8 mm, horizontal field of view 105.8°
• Lens Mount: M12
• Aperture: F2.0

Illuminator

• Supplement Light Type: IR
• Supplement Light Range: Up to 5 meters

• Video
• Main Stream: 50 Hz: 25 fps (1920 × 1080, 1280 ×720),60Hz: 30fps (1920 × 1080, 1280 ×720)
• Sub-Stream: 50 Hz: 25 fps (704 × 576, 352 × 288, 640 × 480, 320 × 240),60 Hz: 30 fps (704 × 480, 352 × 240, 640 × 480, 320 × 240)
• Video Bit Rate: 32 Kbps – 8 Mbps
• Video Compression: Main stream: H.264,Sub stream: H.264
• H.264 Type: Baseline Profile/Main Profile
• Region Of Interest (ROI): Support 1 fixed region for each stream

Audio

• Audio Type: Support mono soundtrack
• Audio Compression: G.711/G.722.1/G.726/MP2L2/PCM
• Audio Bit Rate: 64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-160Kbps(MP2L2)
• Audio Sampling Rate: Max. 16 kHz
• Environment Noise Filtering: Support

Network

• Network Storage: Support Micro SD/SDHC/SDXC card, up to 128 GB local storage

Wi-Fi

• Encryption Mode: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK, WPS
• Wi-Fi Protocol: 802.11b: CCK, QPSK, BPSK, 802.11g/n: OFDM
• Frequency Range: 2.4 GHz – 2.4835 GHz
• Channel Bandwidth: 20/40 MHz Support
• Transfer Rate: 11b: 11 Mbps, 11g: 54 Mbps, 11n: up to 150 Mbps
• Wireless Range: 50 meters (The performance varies based on actual environment)


• Image Settings: Brightness, saturation, sharpness, contrast are adjustable via client software
• Day/Night Switch: Support auto/scheduled
• Wide Dynamic Range (WDR): Digital WDR
• Image Enhancement: BLC，3D DNR

Interface

• Ethernet Interface: 1 RJ45 10 M/100 M self-adaptive Ethernet port
• On-Board Storage: Built-in microSD/SDHC/SDXC slot, up to 128 GB
• Audio: Support mono soundtrack, 1 build-in microphone, 1 build-in speaker
• Reset Key: Yes

Event

• Basic Event: Motion Detection，Video Tampering Alarm, excepetion(HDD Full, HDD Error, Network Disconnected, IP Address Conflicted, Illegal Login)

General

• Power: DC 5V ± 10 %，Max. 1.4 A, Max. 7 W，micro USB interface
• Material: Plastic
• Dimension: Φ 82.4 × 113.6 mm (Φ 3.25” × 4.47”)
• Weight: Approx. 510 g (1.12 lb)
• Startup And Operating Conditions: -10 °C to 40 °C (14 °F to 104 °F), Humidity 95% or less (non-condensing)
• General Function: One-key reset, Anti-flicker, Heartbeat, Mirror, Password Protection, Privacy Mask, Watermark
